광학 매개 변수 테이블:

	Product model	Mag	WD	Image circle	For pixel size	F#	Mount	Distortion	Depth of Field	Lens Length	Download
Object Telecentric Lens Image circle 2/3"(∅ 11mm)
	GAGE110/030-C3.75-11	0.3X	110mm	2/3"(∅ 11mm)	3.75μm	F5.6	C口	<0.02%	0.5mm	116.94mm
	GAGE110/050-C11-11	0.5X	110mm	2/3"(∅ 11mm)	11μm	F9.6	C口	<0.05%	1mm	121.90mm
	GAGE110/080-C6.25-11	0.8X	110mm	2/3"(∅ 11mm)	6.25μm	F11	C口	<0.05%	1mm	117.79mm
	GAGE110/100-C5-11	1X	110mm	2/3"(∅ 11mm)	5μm	F11	C口	<0.05%	1mm	130.59mm
	GAGE110/150-C5-11	1.5X	110mm	2/3"(∅ 11mm)	5μm	F10	C口	<0.04%	0.18mm	128.87mm
	GAGE110/200-C5-11	2X	110mm	2/3"(∅ 11mm)	5μm	F12.2	C口	<0.02%	0.12mm	133.44mm
	GAGE110/300-C5-11	3X	110mm	2/3"(∅ 11mm)	5μm	F18.3	C口	<0.02%	0.08mm	165.67mm
	GAGE110/400-C5-11	4X	110mm	2/3"(∅ 11mm)	5μm	F22	C口	<0.02%	0.06mm	130.71mm

	Product model	Mag	WD	Image circle	FOV	F#	Mount	Distortion	Depth of Field	MTF30 (lp/mm)	Length of I/O	Telecentricity	Download
Bi-telecentric Lens Image circle 1.1"(∅ 17.6mm)
	GAGE138/0334-55-18	0.334X	138mm	1.1"(∅ 17.6mm)	55mm	F6	C口	<0.1%	±1.5mm	>130	343.5mm	<0.1°
	GAGE159/0292-63-18	0.292X	159mm	1.1"(∅ 17.6mm)	63mm	F5	C口	<0.1%	±2mm	>120	371.1mm	<0.1°
	GAGE178/0260-71-18	0.260X	178mm	1.1"(∅ 17.6mm)	71mm	F6.3	C口	<0.1%	±3mm	>130	416mm	<0.1°
	GAGE229/0233-79-18	0.233X	229mm	1.1"(∅ 17.6mm)	79mm	F8	C口	<0.1%	±6mm	>115	457.1mm	<0.1°
	GAGE254/0201-92-18	0.201X	254mm	1.1"(∅ 17.6mm)	92mm	F8	C口	<0.1%	±6.5mm	>105	497.7mm	<0.1°
	GAGE251/0168-110-18	0.168X	251mm	1.1"(∅ 17.6mm)	110mm	F5	C口	<0.1%	±5mm	>120	554.3mm	<0.1°
	GAGE288/0138-134-18	0.138X	288mm	1.1"(∅ 17.6mm)	134mm	F5	C口	<0.1%	±9.5mm	>125	707.8mm	<0.1°
	GAGE301/0125-148-18	0.125X	301mm	1.1"(∅ 17.6mm)	148mm	F5	C口	<0.1%	±10mm	>130	683.5mm	<0.1°

	Product model	Mag	WD	Image circle	FOV	F#	Mount	Distortion	Depth of Field	MTF30 (lp/mm)	Length of I/O	Telecentricity	Download
Bi-telecentric Lens Image circle 35mm
	GAGE138/0781-56-35	0.781X	138mm	35mm	56mm	F12	F/M58	<0.1%	±3mm	>80	417.9mm	<0.1°
	GAGE159/0682-64-35	0.682X	159mm	35mm	64mm	F10	F/M58	<0.1%	±1.5mm	>75	445mm	<0.1°
	GAGE178/0607-72-35	0.607X	178mm	35mm	72mm	F10.2	F/M58	<0.1%	±2mm	>70	490mm	<0.1°
	GAGE229/0546-80-35	0.546X	229mm	35mm	80mm	F16	F/M58	<0.1%	±2mm	>35	531.6mm	<0.1°
	GAGE253/0468-94-35	0.468X	253mm	35mm	94mm	F18	F/M58	<0.1%	±3mm	>50	573.3mm	<0.1°
	GAGE251/0392-112-35	0.392X	251mm	35mm	112mm	F8	F/M58	<0.1%	±3mm	>65	628.8mm	<0.1°
	GAGE288/0321-137-35	0.321X	288mm	35mm	137mm	F6.2	F/M58	<0.1%	±2mm	>85	783.3mm	<0.1°
	GAGE301/0292-150-35	0.292X	301mm	35mm	150mm	F10	F/M58	<0.1%	±6mm	>80	757.2mm	<0.1°

주요 특징

. Large DOF 디자인, 균형잡힌 해상도, F 값

. 3D object에 대한 왜곡률 최소

. 이미지의 중심부에서 가장자리까지 선명한 이미지

. 고해상도

. Bi-telecentric 렌즈

. 광학기구의 안정적인 디자인

. 설치가 간단한 독특한 디자인

적용 분야

. 광학 측정

. 기계적 부품의 검사

. 플라스틱 제품의 검사

. 의학용 검사

. 외곽선 측정

. 전자 분야의 검사

. 휴대폰 검사
